A versatile Fiber Breakout Box, designed for rapid deployment in telecom, data‑center, and field installations, provides reliable fiber management and protection. Its rugged enclosure safeguards delicate fiber connections against moisture, dust, and mechanical stress, while the intuitive layout simplifies splicing, testing, and troubleshooting. Ideal for tower, wind, solar, and utility projects, this compact solution streamlines network expansions and maintenance, ensuring high‑performance signal integrity across demanding environments.
– High‑density 12‑port configuration for efficient space utilization
– Quick‑release clamps reduce installation time and minimize fiber stress
– UV‑resistant, IP66‑rated housing for outdoor durability
– Low‑loss, precision‑aligned adapters maintain signal quality
– Modular design allows easy expansion and reconfiguration
– Tool‑free snap‑in panels for hassle‑free maintenance
– Dimensions: 5.5 in × 3.2 in × 1.4 in (140 mm × 81 mm × 36 mm)
– Weight: 1.2 lb (0.55 kg)
– Material: UV‑stabilized polycarbonate enclosure with stainless‑steel clamps
– Operating temperature: –40 °C to +85 °C (–40 °F to 185 °F)
– Insertion loss: ≤ 0.2 dB per port
– Compliance: RoHS, CE, FCC Part 15 (Class B)
– Connector types: LC/SC compatible adapters, optional hybrid kits available
